Valley Shaped
Three Hump Camel Function¶
Three-hump camel function.
The three-hump camel function is a two-dimensional function with three minima, where one of the minima is a global minimum.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import ThreeHumpCamelFunction
>>> x = np.linspace(-5, 5, 100)
>>> y = np.linspace(-5, 5, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = ThreeHumpCamelFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("ThreeHumpCamelFunction.png", dpi=300, transparent=True)
Notes
The three-hump camel function is defined as:
Reference: Original implementation can be found here.
Parameters:
Name | Type | Description | Default |
---|---|---|---|
*x | UniversalArray | Input data, which has to be two-dimensional. | () |
Raises:
Type | Description |
---|---|
OutOfDimensionError | If the dimension of the input data is not 2. |
Source code in umf/functions/optimization/valley_shaped.py
class ThreeHumpCamelFunction(OptFunction):
r"""Three-hump camel function.
The three-hump camel function is a two-dimensional function with three
minima, where one of the minima is a global minimum.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import ThreeHumpCamelFunction
>>> x = np.linspace(-5, 5, 100)
>>> y = np.linspace(-5, 5, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = ThreeHumpCamelFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("ThreeHumpCamelFunction.png", dpi=300, transparent=True)
Notes:
The three-hump camel function is defined as:
$$
f(x) = 2x_1^2 - 1.05x_1^4 + \frac{x_1^6}{6} + x_1x_2 + x_2^2
$$
> Reference: Original implementation can be found
> [here](https://www.sfu.ca/~ssurjano/camel3.html).
Args:
*x (UniversalArray): Input data, which has to be two-dimensional.
Raises:
OutOfDimensionError: If the dimension of the input data is not 2.
"""
def __init__(self, *x: UniversalArray) -> None:
"""Initialize the three-hump camel function."""
if len(x) != __2d__:
raise OutOfDimensionError(
function_name="ThreeHumpCamel",
dimension=__2d__,
)
super().__init__(*x)
@property
def __eval__(self) -> UniversalArray:
"""Evaluate the three-hump camel function at x."""
x_1 = self._x[0]
x_2 = self._x[1]
return 2 * x_1**2 - 1.05 * x_1**4 + (x_1**6) / 6 + x_1 * x_2 + x_2**2
@property
def __minima__(self) -> MinimaAPI:
"""Return the minima of the three-hump camel function."""
return MinimaAPI(
f_x=np.array([0.0, 0.0]),
x=tuple(np.array([0.0])),
)
Six Hump Camel Function¶
Six-hump camel function.
The six-hump camel function is a two-dimensional function with six minima, where two of them are global minima.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import SixHumpCamelFunction
>>> x = np.linspace(-3, 3, 100)
>>> y = np.linspace(-2, 2, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = SixHumpCamelFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("SixHumpCamelFunction.png", dpi=300, transparent=True)
Notes
The six-hump camel function is defined as:
Reference: Original implementation can be found here.
Parameters:
Name | Type | Description | Default |
---|---|---|---|
*x | UniversalArray | Input data, which has to be two-dimensional. | () |
Raises:
Type | Description |
---|---|
OutOfDimensionError | If the dimension of the input data is not 2. |
Source code in umf/functions/optimization/valley_shaped.py
class SixHumpCamelFunction(OptFunction):
r"""Six-hump camel function.
The six-hump camel function is a two-dimensional function with six
minima, where two of them are global minima.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import SixHumpCamelFunction
>>> x = np.linspace(-3, 3, 100)
>>> y = np.linspace(-2, 2, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = SixHumpCamelFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("SixHumpCamelFunction.png", dpi=300, transparent=True)
Notes:
The six-hump camel function is defined as:
$$
f(x) = (4 - 2.1x_1^2 + \frac{x_1^4}{3})x_1^2 + x_1x_2 + (-4 + 4x_2^2)x_2^2
$$
> Reference: Original implementation can be found
> [here](https://www.sfu.ca/~ssurjano/camel6.html).
Args:
*x (UniversalArray): Input data, which has to be two-dimensional.
Raises:
OutOfDimensionError: If the dimension of the input data is not 2.
"""
def __init__(self, *x: UniversalArray) -> None:
"""Initialize the six-hump camel function."""
if len(x) != __2d__:
raise OutOfDimensionError(
function_name="SixHumpCamel",
dimension=__2d__,
)
super().__init__(*x)
@property
def __eval__(self) -> UniversalArray:
"""Evaluate the six-hump camel function at x."""
x_1 = self._x[0]
x_2 = self._x[1]
return (
(4 - 2.1 * x_1**2 + (x_1**4) / 3) * x_1**2
+ x_1 * x_2
+ (-4 + 4 * x_2**2) * x_2**2
)
@property
def __minima__(self) -> MinimaAPI:
"""Return the minima of the six-hump camel function."""
return MinimaAPI(
f_x=-1.031628453489877,
x=tuple(np.array([0.0898, -0.7126], [-0.0898, 0.7126])),
)
Dixon-Price Function¶
Dixon-Price function.
The Dixon-Price function is a multi-dimensional function with a single global minimum.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import DixonPriceFunction
>>> x = np.linspace(-10, 10, 100)
>>> y = np.linspace(-10, 10, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = DixonPriceFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("DixonPriceFunction.png", dpi=300, transparent=True)
Notes
The Dixon-Price function is defined as:
Reference: Original implementation can be found here.
Parameters:
Name | Type | Description | Default |
---|---|---|---|
*x | UniversalArray | Input data, which has to be two-dimensional. | () |
Raises:
Type | Description |
---|---|
TooSmallDimensionError | If the dimension of the input data is smaller than 2. |
Source code in umf/functions/optimization/valley_shaped.py
class DixonPriceFunction(OptFunction):
r"""Dixon-Price function.
The Dixon-Price function is a multi-dimensional function with a single
global minimum.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import DixonPriceFunction
>>> x = np.linspace(-10, 10, 100)
>>> y = np.linspace(-10, 10, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = DixonPriceFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("DixonPriceFunction.png", dpi=300, transparent=True)
Notes:
The Dixon-Price function is defined as:
$$
f(x) = (x_1 - 1)^2 + \sum_{i=2}^n \left[ i(x_i - x_{i-1}^2)^2 \right]
$$
> Reference: Original implementation can be found
> [here](https://www.sfu.ca/~ssurjano/dixonpr.html).
Args:
*x (UniversalArray): Input data, which has to be two-dimensional.
Raises:
TooSmallDimensionError: If the dimension of the input data is smaller than 2.
"""
def __init__(self, *x: UniversalArray) -> None:
"""Initialize the Dixon-Price function."""
if len(x) < __2d__:
raise TooSmallDimensionError(
function_name="DixonPrice",
dimension=__2d__,
len_x=len(x),
)
super().__init__(*x)
@property
def __eval__(self) -> UniversalArray:
"""Evaluate Dixon-Price function at x."""
x = self._x
return (x[0] - 1) ** 2 + sum(
(i + 1) * (x[i] - x[i - 1] ** 2) ** 2 for i in range(1, len(x))
)
@property
def __minima__(self) -> MinimaAPI:
"""Return the zero function."""
return MinimaAPI(
f_x=0.0,
x=tuple(np.array([2 ** (-i) for i in range(1, len(self._x) + 1)])),
)
Rosenbrock Function¶
Rosenbrock function.
The Rosenbrock function is a multi-dimensional function with a single global minimum.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import RosenbrockFunction
>>> x = np.linspace(-2, 2, 100)
>>> y = np.linspace(-1, 3, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = RosenbrockFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("RosenbrockFunction.png", dpi=300, transparent=True)
Notes
The Rosenbrock function is defined as:
Reference: Original implementation can be found here.
Parameters:
Name | Type | Description | Default |
---|---|---|---|
*x | UniversalArray | Input data, which has to be two-dimensional. | () |
Raises:
Type | Description |
---|---|
TooSmallDimensionError | If the dimension of the input data is smaller than 2. |
Source code in umf/functions/optimization/valley_shaped.py
class RosenbrockFunction(OptFunction):
r"""Rosenbrock function.
The Rosenbrock function is a multi-dimensional function with a single
global minimum.
Examples:
>>> import matplotlib.pyplot as plt
>>> import numpy as np
>>> from umf.functions.optimization.valley_shaped import RosenbrockFunction
>>> x = np.linspace(-2, 2, 100)
>>> y = np.linspace(-1, 3, 100)
>>> X, Y = np.meshgrid(x, y)
>>> Z = RosenbrockFunction(X, Y).__eval__
>>> fig = plt.figure()
>>> ax = fig.add_subplot(111, projection="3d")
>>> _ = ax.plot_surface(X, Y, Z, cmap="viridis")
>>> plt.savefig("RosenbrockFunction.png", dpi=300, transparent=True)
Notes:
The Rosenbrock function is defined as:
$$
f(x) = \sum_{i=1}^{n-1} \left[ 100(x_{i+1} - x_i^2)^2 + (1 - x_i)^2 \right]
$$
> Reference: Original implementation can be found
> [here](https://www.sfu.ca/~ssurjano/rosen.html).
Args:
*x (UniversalArray): Input data, which has to be two-dimensional.
Raises:
TooSmallDimensionError: If the dimension of the input data is smaller than 2.
"""
def __init__(self, *x: UniversalArray) -> None:
"""Initialize the Rosenbrock function."""
if len(x) < __2d__:
raise TooSmallDimensionError(
function_name="Rosenbrock",
dimension=__2d__,
len_x=len(x),
)
super().__init__(*x)
@property
def __eval__(self) -> UniversalArray:
"""Evaluate Rosenbrock function at x."""
x = self._x
return np.array(
sum(
100 * (x[i + 1] - x[i] ** 2) ** 2 + (1 - x[i]) ** 2
for i in range(len(x) - 1)
),
)
@property
def __minima__(self) -> MinimaAPI:
"""Return the zero function."""
return MinimaAPI(
f_x=0.0,
x=tuple(np.array([1.0 for _ in range(len(self._x))])),
)
